Linea
design _BLANK | DESIGN STUDIO + GERARDO MARI
Linea is a system made of flexible LED linear lighting elements. Made with a harmonic steel core, Linea can be stretched between two walls, not necessarily parallel, thanks to the tensile joints at the ends of the system. It can also be ceiling-mounted and turned into free geometric shapes thanks to the brackets that manage the core of the lamp. A silicone cover allows a consistent diffusion of the light generated by two opposing LED strips with a combined power up to 1,900 lumens/meter.
Technical information
| Code | W | K | Lumen | CRI | Dimensions |
|---|---|---|---|---|---|
| 1795.L1 | LED 20W | 3000°K 2700°K |
1900 Lumen 1700 Lumen |
CRI 90 | 1 mt |
| 1795.L2 | LED 40W | 3000°K 2700°K |
3800 Lumen 3400 Lumen |
CRI 90 | 2 mt |
| 1795.L3 | LED 60W | 3000°K 2700°K |
5700 Lumen 5100 Lumen |
CRI 90 | 3 mt |
| 1795.L4 | LED 80W | 3000°K 2700°K |
7600 Lumen 6800 Lumen |
CRI 90 | 4 mt |
| 1795.L5 | LED 100W | 3000°K 2700°K |
9500 Lumen 8500 Lumen |
CRI 90 | 5 mt |
| 1795.L6 | LED 120W | 3000°K 2700°K |
11400 Lumen 10200 Lumen |
CRI 90 | 6 mt |
| 1795.L7 | LED 140W | 3000°K 2700°K |
13300 Lumen 11900 Lumen |
CRI 90 | 7 mt |
| 1795.L8 | LED 160W | 3000°K 2700°K |
15200 Lumen 13600 Lumen |
CRI 90 | 8 mt |
| 1795.L9 | LED 180W | 3000°K 2700°K |
17100 Lumen 15300 Lumen |
CRI 90 | 9 mt |
| 1795.L10 | LED 200W | 3000°K 2700°K |
19000 Lumen 17000 Lumen |
CRI 90 | 10 mt |
